THE EVERGLADES HOUSE
|
Floor Plan with Dimensions & Elevations
$50.00 PDF Version:
Delivered via e-mail. Save on shipping and printing; print as many copies as needed. $1200.00 Five Copy Construction Set:
Delivered bond paper. NO MODIFICATIONS ALLOWED. $1400.00 |
Most plans come with: Detailed floor plans, exterior elevations, front perspective, foundation plans, house and detailed cross sections, and floor structural supports. A free specification outline is included with every purchase.
Customize your plan purchase with upgrades such as: Lighting design, alternate foundations, multiple/unlimited use licenses, additional plans, materials list, mirror reverse, right reading reverse, line rendering, color rendering, home furniture planner, and personalized customizations.
Customize your plan purchase with upgrades such as: Lighting design, alternate foundations, multiple/unlimited use licenses, additional plans, materials list, mirror reverse, right reading reverse, line rendering, color rendering, home furniture planner, and personalized customizations.
|
Plan Details
Heated/living area 2,216 sq. ft. Garage area 512 sq. ft. Foundations slab on grade CMU & wood framing Hardie board siding Roof material asphalt Roof framing combination truss/conventional First floor 1704 sq ft/ height 10' 0" Second floor 512 sq ft/ height 8' 0" Covered lanai 246 sq ft Master bedroom 279 sq ft / width x depth 19' 11'' x 14' 0'' Bedroom 2 156 sq ft / width x depth 14' 10'' x 10' 6'' Bedroom 3 137 sq ft / width x depth 11' 9'' x 11' 8'' Bedroom 4 127 sq ft / width x depth 10' 3' x 12' 4 1/2'' Den 116 sq ft / width x depth 10' 7 1/2'' x 10' 11'' Music room 215 sq ft / width x depth 14' 8'' x 14' 8'' Living room 283 sq ft / width x depth 17' 4'' x 16' 4'' Kitchen/ dinning 390 sq ft / width x depth 19' 2'' x 20' 4'' |
Plan Features
Exterior features: Covered rear lanai Covered entry Car features: Two car garage with storage Main features: Music room Split floor plan Open living space Kitchen features: Open layout Island Pantry Bed and bath features: Walk-in closet His and hers vanity |
